How to Ensure Your Quick Turn PCB Will Not Be Delayed

Angie Brown
Written by Angie Brown
Posted on January 19, 2017 at 3:57 PM
Angie Brown

When a project depends on quick-turn printed circuit boards, delays can affect schedules, assembly timelines, and product delivery commitments. While PCB fabricators are responsible for manufacturing performance, customers can play a significant role in preventing avoidable production holds.

Working with a high-quality quick-turn PCB supplier is an important first step. Equally important is providing complete and accurate manufacturing information so fabrication can begin without unnecessary questions, revisions, or data clarification requests.

A circuit board supplier's ability to meet aggressive lead times depends on both manufacturing capability and the quality of the information received with the order. In many cases, delays occur because critical fabrication details are missing, unclear, or discovered too late in the process.

Download Our Ebook To Learn How Your PCB Quote Can Impact Your Delivery

How to Ensure Your Quick Turn PCB Will Not Be Delayed

Use DFM Review Early in the Design Process

One of the most effective ways to reduce front-end delays is to use a Design for Manufacturability (DFM) service during the design and prototyping stages.

A DFM review can identify hidden manufacturing issues before an order is released to production. Discovering these issues early allows corrections to be made before fabrication begins, helping to avoid schedule impacts caused by engineering revisions or updated PCB data.

When manufacturability concerns are found only after boards have been produced, lead times can increase as design files are revised and production schedules are adjusted. Early DFM review helps reduce that risk and supports a smoother path to fabrication.

Submit a Complete PCB Manufacturing Data Package

Incomplete manufacturing data is one of the most common causes of production delays. To support quick-turn fabrication, provide a complete data package that includes:

  • Gerber files, preferably in RS274X format, ODB++
  • Excellon drill data
  • A clean and accurate 1:1 PCB outline profile
  • A fabrication drawing

In addition to design data, specify key manufacturing requirements such as:

  • Overall circuit board thickness
  • Internal and external finished copper weights
  • Soldermask color
  • Silkscreen color
  • Required surface finish

Providing these details up front helps ensure that quotation, tooling, and manufacturing activities can proceed without interruption.

Common Front-End Issues That Delay Quick-Turn PCB Orders

Even when a PCB fabricator has the capacity to meet aggressive lead times, missing or unclear manufacturing information can prevent production from starting on schedule. The most common issues include missing drill programs, incomplete fabrication requirements, unspecified surface finishes, undefined copper weights, and absent board construction details. Without this information, engineering teams must place the order on hold while clarification is requested, creating avoidable delays before fabrication can begin.

Pre-production CAM engineering review plays a critical role in preventing these schedule impacts. Many manufacturing issues are identified before production through checks that verify trace and space requirements, copper-to-edge clearances, plated versus non-plated hole definitions, impedance requirements, and fabrication tolerances. By identifying these issues early, manufacturers can address potential problems before they affect tooling, material selection, or production scheduling. Providing complete documentation up front remains one of the most effective ways to keep a quick-turn PCB order moving through the manufacturing process without interruption.

Define Critical Tolerances and Manufacturing Requirements

Fabrication drawings should clearly identify dimensions and tolerances that must be maintained during production.

The following tolerances are recommended for ease of manufacturing:

  • Routing: +/-0.005"
  • Plated holes: +/-0.003"
  • Non-plated through holes: +/-0.002"

Critical dimensions and special manufacturing requirements should also be clearly called out on the fabrication drawing. Important requirements may include:

  • Press-fit holes
  • Impedance controls
  • RoHS-compliant construction
  • IPC production class II or class III requirements

Providing this information early supports more accurate quotations and helps ensure the PCB is manufactured to the intended specification.

Provide Array and Panelization Requirements

Array requirements should be defined before fabrication begins.

Specify whether scoring or routing is preferred and ensure the design data supports the selected approach. Copper should be kept away from PCB edges as required for processing.

When available, include detailed array information in a drawing with clearly defined dimensions and processing requirements. Clear panelization guidance helps prevent manufacturing questions that can place an order on hold.

Specify Laminate Requirements Correctly

Material specifications can also influence manufacturing efficiency.

Understanding basic laminate requirements, including Tg values, helps ensure the appropriate material is selected without unnecessary delays.

  • 130Tg is described as a standard material commonly used in non-RoHS applications and simpler product designs.
  • 170Tg is used when printed circuit boards must withstand multiple RoHS assembly cycles at higher temperatures.
  • 180Tg is intended for high-reliability, double-sided surface-mount PCB applications.

Material requirements should be specified according to Tg requirements rather than a specific laminate brand whenever possible. This approach can help streamline material selection and support quicker production.

It is also important to avoid specifying a higher Tg material than the application requires, since doing so may increase product cost without providing a meaningful benefit.

Reducing the Risk of Quick-Turn PCB Delays

Quick-turn PCB schedules depend on more than manufacturing capacity alone. Complete design data, clear fabrication requirements, appropriate material specifications, and early DFM review all contribute to a faster and more predictable manufacturing process.

Providing a complete PCB data package and clearly defining manufacturing expectations can eliminate many of the common issues that cause PCB orders to be delayed or placed on hold.

Not Sure If Your PCB Design Is Manufacturable? Submit a FREE DFM Today!

Summary

Submitting a complete PCB data package ensures you will receive your quick turn printed circuit boards on time. Following these guidelines will fulfill important PCB order requirements and eliminate many of the issues that could cause your circuit board order to be placed on hold.


Key Takeaways

  • Use DFM services early: A free Design for Manufacturability review during the design phase helps uncover and fix hidden issues before orders are placed, avoiding costly revisions and delays.
  • Submit a complete data package: Provide Gerber files, drill data, accurate PCB outlines, and a clear fabrication drawing to prevent production holds.
  • Define materials and finishes correctly: Specify overall thickness, copper weights, soldermask and silkscreen colors, and the desired surface finish in your order.
  • Call out tolerances and standards: Include IPC class requirements, critical dimensions, and terms like press-fit holes or impedance controls to ensure accurate builds and quicker quoting.
  • Clarify laminate and array requirements: Provide Tg specifications (130Tg, 170Tg, or 180Tg as appropriate) and array details such as scoring vs. routing to streamline processing and avoid unnecessary cost or delays.
